STEP L3DSD2 Fully Automatic Double Rotary Arm Stretch Wrapper with Top Sheet Dispenser

STEP L3DSD2 Fully Automatic Double Rotary Arm Stretch Wrapper with Top Sheet Dispenser – is designed and equipped with Double Film Carriage, one for each side to properly secure the wrapping. Equipped with a Top Sheet Dispenser installed on top of the conveyor line, suitable for products that need watertight wrapping.

Features:

• Rotary speed, film carriage speed and the film tension can adjustable
• Automatic stretch film application & cutting is Pneumatically driven
• Equipped with Automatic height detection by photocell
• Machine is equipped with various durable top of the line components
• Equipped with Alarm and Emergency Button for Operators Safety
• PLC Controls the whole system with User Friendly Control Panel (HMI)
• Powered Roller Conveyor Line is made of galvanized carbon steel

Options:

• Wrap height 2400mm or 2600mm. Load size could be custom made to specific applications
•  Safety fencing for better protection of operators
• Infeed/outfeed conveyors
